Click the Base Heights tab, and under the Elevation from features section, specify the factor to convert the shapefile elevation values in the scene.

Right-click this shapefile in the Table of Contents, and click Properties. After the new shapefile is created, open ArcScene from the 3D Analyst toolbar, and add the new shapefile (Add Data) to the scene.

Under Height Field, select the field to be used for the 'elevation' of the features.

Specify a location for the 3D shapefile in the Output Feature Class box.

In the Feature To 3D By Attribute window, select the 2D shapefile as the Input Feature.

If the elevation values do not come from a field in the shapefile's attribute table, but rather from a 3D surface, disregard steps 3 through 7 and read the following ArcGIS Web Help documentation for more information: Deriving the existing features' heights from a surface

Open the Feature To 3D By Attribute tool.

Open ArcToolbox, and navigate to 3D Analyst Tools > 3D Features.

Check 3D Analyst if it is not already checked.

Verify that the 3D Analyst extension is activated by navigating to Customize > Extensions.

To learn more, read Creating 3D feature data. 2D data cannot be converted into 3D data unless it has been sufficiently prepared for the conversion. Thus, follow the steps below that coincide with the version of ArcMap installed on the computer.īefore converting the shapefile, ensure that the attribute table data from the shapefile contains a field that can be used as the 'elevation' measurement, often called the Z-value.

2D TO 3D CONVERSION IN CORTEX HOW TO

The instructions provided describe how to convert a 2D shapefile to a 3D shapefile using the 3D Analyst extension in ArcMap.ĭepending on the version of ArcMap, the workflow is different.
